一、产品简介
I Product Introduction
本品是一酸性的清洁剂,用于清洁印刷线路板铜面的氧化与有机污染物,而不攻击干膜、有机油墨等。
The product is a sort of acid cleaner, and is used to clean oxide and organic pollutants on copper surface of print circuit board without attaching dry film and organic ink, etc.
二、使用方法
II Using Method
1、建浴标准
1. Makeup Standard
1L槽液
1L solutioin |
主要作用
Main Function |
体积(ml)
Volume |
纯水
Pure water |
溶剂
Solvent |
950-900ml |
除油剂
Deoiling agent |
除油
Deoiling |
50-100ml |
2、操作条件
2. Operating Condition
组份/参数
Component/Parameter |
最佳值/工作范围/要求
Optimal value/Work Scope/Requirement |
温 度
Temperature |
25℃(20-30℃) |
时 间
Time |
4min(3-5min) |
过 滤
Filter |
连续过滤
Continuous filter |
搅 拌
Mixing |
工件移动
Movement of workpiece |
三、槽液的控制与维护
III Control and Maintenance of Solution
控制项目
Control Item |
控制范围
Control Scope |
最佳值
Optimal value |
分析频率
Analyziz Frequency |
添加量
Additive Volume |
备注
Remark |
酸当量
Acid equivalent |
0.3-0.8N |
0.6N |
每班一次
Once per shift |
每添加10ml/L 除油剂,酸当量约升高0.1N
Acid equivalent increases about 0.1N upon adding 10ml/L Deoiling agent |
/ |
铜离子
Copper ion |
<2g/L |
/ |
每天一次
Once per day |
/ |
/ |
1、除油的标准添加量为1-2L/100m2;
1. Standard adding amount of Deoiling agent is 1-2L/100m2;
2、当铜含量高于2g/L或每升工作液处理8-10mP2P 板时,请更新槽液;
2. When copper content is higher than 2g/L or 1L working solution processing 8-10mP2P board, please replace solution;
3、当槽液混浊,有大量沉淀时,请更新槽液;
3. When solution is turbid and has plenty deposit, please replace solution;
4、当小孔、残渣或显影效果不好时,可提高除油剂浓度至10%。
4. In case of small hole, residue or bad developing effect, improve concentration of Deoiling agent to 10%;
4、产品性状
IV Product Property
名称
Product name |
外观
Appearance |
比重(g/cmP3P)
Specific Gravity |
酸当量(N)
Acid equivalent |
有效期
Valid Period |
除油剂
Deoiling agent |
无色至淡黄色透明液体
Colorless to light yellow transparent liquid |
1.30±0.05 |
11.0±0.5 |
12个月
12 months |
五、分析方法
V Analysis Method
槽液酸当量分析
Analysis of acid equivalent of solution
1、取2mL稀释液加入250mL锥形瓶中,再加纯水50mL;
1. Take 2ml dilute solution into a 250ml conical flask, and then add 50ml pure water;
2、加3-5滴甲基红指示剂;
2. Add 3-5 drops of methyl red indicator;
3、用0.1N NaoH滴定,滴至溶液由红色变为黄色为终点。
3. Use 0.1N NaoH for titration till the solution turns from red to yellow;
计 算:酸当量(N)=0.1 × V0.1N NaoH(ml)÷2
Calculation: acid equivalent (N) = 0.1 × V0.1N NaoH(ml)÷2
六、注意事项
VI Notes
1、产品存储请放置阴凉处,避免日晒,以防止产品变质;
1. The product shall be stored in a cool place being away from sunshine;
2、药水开封后请在一月内使用完;
2. The solution shall be used up within one monthe after unsealing;
3、PC-658为酸性液体,使用时请戴耐酸碱手套、防护眼镜,若药液不慎溅及皮肤、眼睛时应用大量清水清洗,严重者应立即就医诊治。
3. PC-658 is acid liquid, and when using it, please wear acid alkali resistant gloves and protective glasses; in case that solution spatters into eye or on skin, immediately flush with plenty of clean water and get medical treatment if necessary;
七、安全防护
VII Safety Protection
PC-658为酸性液体,使用时请佩戴眼罩、手套及穿安全防护衣。若药液不慎溅及皮肤、眼睛时应用大量清水清洗,严重者应立即就医诊治。
PC-658 is acid liquid, and when using it, please wear eyeshade, gloves and protective clothes; in case that solution spatters into eye or on skin, immediately flush with plenty of clean water and get medical treatment if necessary. |
