一、产品简介
I Product Introduction
SB-675能很好地抑制硝酸剥蚀金属时产生的NO2等有毒气体,提高剥蚀速度,达到改善环境目的。
SB-675 can well restrain such noxious gas as NO2 from stripping metal by nitric acid and improve stripping velocity to improve environment.
1.配槽方法
II Makeup Method
1.建浴标准
1. Makeup Standard
1L槽液
1L solutioin |
主要作用
Main Function |
体积(ml)
Volume |
纯水
Pure water |
溶剂
Solvent |
450-770ml |
68%硝酸
68% nitric acid |
脱挂架上铜点
Remove copper point of rack |
200-500ml |
SB-675 |
抑制硝烟
Restrain smoke |
30-50ml |
操作条件
2. Operating Condition
组份/参数
Component/Parameter |
最佳值/工作范围/要求
Optimal value/Work Scope/Requirement |
温 度
Temperature |
25℃(20-30℃) |
时 间
Time |
2min(1-3min) |
过 滤
Filter |
连续过滤
Continuous filter |
搅 拌
Mixing |
工件移动
Movement of workpiece |
三、槽液维护
III Maintenance of Solution
开 缸 量:以硝酸槽体3-5%开缸
Open-cylinder amount: open cylinder with nitric acid 3-5% to bath
标准补充:依化学分析结果补充NHO3及相应硝酸抑制剂量,分析频率1次/天。
Standard supplement: supplement NHO3 and related amount of nitric acid inhibitor according to chemical analysis and analyze frequency once per day;
更新溶液:铜含量达到75g/L时请更槽。
Replace solution: replace when copper content reaches 75g/L;
四、分析方法
IV Analysis Method
1、HNO3含量分析
1. Analysis of content of HNO3
(1)取1ml槽液称量计重m,加入到250ml锥形瓶中,加DI水50-100ml;
(1) Take 1ml solution weigh as m, add it into a 250ml conical flask, and add 50-100ml DI water;
(2)加酚酞指示剂2-3滴,用1.0 N NaOH标准溶液滴定到出现红色为止;
(2) Add 2-3 drops of Phenolphthalein indicator, use 1.0 N standard NaOH solution for titration till the color turns red;
计算HNO3(%)=6.3 ×V NaOH滴定ml数/m。
Calculation HNO3(%)= 6.3 ×V NaOH titration ml/m
2、Cu2+含量分析
2. Analysis of content of Cu2+
(1)取1ml槽液加入到250ml锥形瓶中,加入DI水100ml;
(1)Take 1ml solution into a 250ml conical flask, and add 100ml DI water;
(2)加入pH为10.5的缓冲溶液20ml;
(2)Add 20ml buffer solution with pH of 10.5;
(3)加入2-3滴PAN指示剂,用0.05N EDTA滴定至草绿色;
(3)Add 2-3 drops of PAN indicator, and use 0.05N EDTA for titration till the color turns grass green;
计算Cu2+(g/L)=3.177×V0.05M EDTA滴定ml数。
Calculation Cu2+(g/L)=3.177×V0.05M EDTA titration ml
五、产品性质
V Product Nature
品名
Product name |
外观
Appearance |
比重
Specific Gravity |
PH 值
PH Value |
闪火点
Flash point |
SB-675 |
无色至淡黄色透明液体
Colorless to light yellow transparent liquid |
1.10±0.05 |
小于1
<1 |
不可燃
Non- combustible |
六、安全防护
VI Safety Protection
SB-675为酸性液体,使用时请佩戴眼罩、手套及穿安全防护衣。若药液不慎溅及皮肤、眼睛时应用大量清水清洗,严重者应立即就医诊治。
SB-675 is acid liquid, and when using it, please wear eyeshade, gloves and protective clothes; in case that solution spatters into eye or on skin, immediately flush with plenty of clean water and get medical treatment if necessary. |
