一、产品简介
I Product Introduction
一般市售之片碱(NaOH),大约含有3%之杂质,这杂质和消泡剂所产生之胶凝物(CEL)极易造成槽壁及管路等等之其它问题及污染,亦可能衍生许多困扰,为因应PCB产品之品质要求日益趋严,遂开发CL—505去膜液,其特殊之添加剂能有效加快去膜速度和延长槽液的寿命,增加产能和减少废水量。
NaOH sold in market usually contains about 3% foreign matters, which, with defoamer, may produce CEL and causes pollution and other problems to bath wall and pipeline; as the requirement on quality of PCB turns strict day by day, CL—505 stripping liquid is designed, and its special additive can effectively speed up stripping and prolong the use life of solution as well as increase output and reduce waste water.
二、产品优势
II Product Advantages
1、剥膜速度快且稳定,增加产能;
1. Stripping is fast and stable, increase productivity;
2、槽液寿命长,大大降低更槽频率,节省废水处理费用;
2. Long use life of solution, greatly reduce frequency for changing bath and save cost for treating waste water;
3、无杂质,降低潜在问题的发生;
3. No foreigh matter, reduce potential problem;
4、达成良好之品质要求。
4. Meet requirement on good quality;
操作方法
III Operating Method
组份/参数
Component/Parameter |
最佳值/工作范围/要求
Optimal value/Work Scope/Requirement |
温 度
Temperature |
55℃(50-60℃) |
浓 度
Concentration |
10±1% |
速 度
Velocity |
依设备和干膜之品牌而有所差异,一般控制在2.4 ~ 2.8M/Min
According to different brands of equipment and dry film, usually controlled within 2.4 - 2.8M/Min |
四、分析方法
IV Analysis Method
槽液方法:
Operating method:
1、取药液5ml稀释于100ml容量瓶中,
1. Take 5ml solution and dilute it in a 100ml bottle;
2、从容量瓶中取1ml于250ml锥形瓶中,
2. Take 1ml solution from the bottle and place it in a 250ml conical flask;
3、加入100ML纯水和3滴酚酞指示剂,
3. Add 100ml pure water and three drops of Phenolphthalein indicator;
4、用0.1N的HCL标准液滴定到红色消失为终点,记下所消耗的毫升数V,
4. Use 0,1N HCL standard solution for titration till the red color disappears, and record the volume V consumed.
(三)计算: 含量=V×20/100×100%
(III) Calculation: capacity= V×20/100×100%
(四)添加方式计算:
(IV) Calculation of adding method:
(标准值-分析值)×槽积=添加量(L)
(standard value – analyzed value) × bath volume = adding amount (L)
五、产品性质
V Product Nature
品名
Product name |
外观
Appearance |
比重
Specific Gravity |
PH 值
PH Value |
闪火点
Flash point |
CL-505 |
无色至淡黄色透明液体
Colorless to light yellow transparent liquid |
1.20-1.40 |
大于12
>12 |
不可燃
Non- combustible |
六、安全防护
VI Safety Protection
CL-505系碱性液体,不可直接接触眼睛,皮肤或衣物若不慎接触到,应立即以大量清洗,并送医诊治。
CL-505 is alkaline liquid and can not directly contact with eyes, skin or clothes; in case of contact, immediately flush with plenty of clean water and get medical treatment. |
