一、产品简介
I Product Introduction
DF-100是一种高浓度非矽消泡剂,具有优良的消泡、抑泡能力,且水溶性良好,乃为PCB制程所设计,应用于退膜、显影及废水处理工序。本品有以下特点:
DF-100 is a sort of high-concentrated non-Si defoamer and has good ability for defoaming and foam inhibition as well as good water-solubility; it is designed for PCB process and is applied in film stripping, developing and treatment of waste water. The product has the following features:
1、低COD值 :废水易处理,减少废液处理之费用;
1. Low COD value: easy treatment of waste water, reduce cost for treating of waste water;
2、水洗性佳 :不造成金属表面残留,影响到下一制程;
2. Good washing ability: not cause residue on metal surface, and influence the next process;
3、不含硅配方:不会造成硅斑残留槽壁,设备易清洗;
3. Silicon-free prescription: not cause silicon spot on bath wall, and the equipment is easy to wash;
4、处理能力强:消泡速度快,抑泡时间长,高稳定不易分解。
4. Strong processing capacity: rapid defoaming and long-term foam inhibition; high stability and not easy to decompose.
二、配槽方法
II Makeup Method
1L槽液
1L solution |
主要作用
Main Function |
体积(ml)
Volume |
DF-100 |
消泡
Defoaming |
0.5ml |
三、操作方法
III Operating Method
1、产品使用前先充分摇晃后再倒出,配槽时以3-5‰之DF-100加入槽液中即可;
1. Before using, fully shake the product and then pour out, use 3-5‰ DF-100 to add into the bath solution;
2、先将原液倒出加水稀释以后再添加,以避免原液分散不均匀;
2. Pour out the raw solution firstly, and then dilute with water and then add it, to avoid unaverage dispersing of raw solution;
3、生产中有泡沫产生时,将消泡剂以水稀释后再添加;
3. When there is foam during production, dilute defoamer with water, and then add it;
4、如有少量分层,可摇匀后再添加,并不影响效果。
4. In case there is seldom delamination, shake it to average and then add it, it will not influence effect.
四、产品性状
IV Product Nature
品名
Product Name |
外观
Appearance |
比重(g/cm3)
Specific Gravity |
DF-100 |
乳白色液体
Milky white liquid |
0.90-1.00 |
五、安全防护
V Safety Protection
DF-100属安全性之消泡剂,皮肤或衣服若不慎接触,以清水冲洗即可。
DF-100 is a safe defoamer; in case of contact with skin or clothes, flush with clean water. |
