一、产品简介
I Product Introduction
单液型显影清槽剂CL-212专用于清洁显影/蚀刻槽喷嘴、滚轮及槽壁干膜、湿膜分解物和附着物。其独特的配方可减少作业时间和达到良好的清洁效果。此清槽剂具有操作简单,清洗效果好,废水排放量少等特点。
Single-liquid developing bath cleaner CL-212 is specially used to remove the decomposer and attachment to the developing/etching bath nozzle, roller and dry and wet film of bath wall. Its special direction can reduce working time and get a good cleaning effect. This agent has such advantages as simple operation, good cleaning effect and less drainage of waste water.
二、配槽方法
II Makeup Method
1L槽液
1L Solution |
主要作用
Main Function |
体积(ml)
Volume |
清水
Clean Water |
溶剂
Solvent |
800-850ml |
CL-212 |
清槽
Cleaning bath |
150-200ml |
三、清洗步骤
III Cleaning Steps
1、将显影槽液完全排放,以清水循环10分钟后完全排放;
1. Drain out solution in bath, and circulate with clean water for 10 minutes, and then drain out water;
2、加入50%左右的清水,开启循环泵,倒入CL—212(15-20%),补水至液位;
2. add about 50% clean water, open circulation pump, and pour in CL—212(15-20%), and add water till liquid level;
3、取出过滤网,并将喷压调至最大,升温至45±3℃,循环喷淋1-2小时;
3. Take out filter net, and adjust jet pressure to the max, raise temperature to 45±3℃, and keep circulated spray;
4、排放清槽液,加入清水循环10分钟及高压水枪冲洗后排放;
4. Drain cleaning solution; add clean water to circulate for 10 minutes, and flush with high pressure water, and then drain out water;
5、拆下所有喷嘴、喷管,将内部清理干净后再安装回原位;
5. Disassemble all nozzles and pipes, clean them, and then install them to original position;
6、以槽体体积的1%加入显影A剂或碳酸钠,清洗20分钟排掉后即可使用设备。
6. Add developing agent A or sodium carbonate with an amount to 1% of the volume of bath to clean for 20 minutes and then drain out the agent, and then the equipment can be used.
四、操作条件
IV Operating Conditions
组份/参数
Component/Parameter |
最佳值/工作范围/要求
Optimal value/Work Scope/Requirement |
浓 度
Concentration |
15-20% |
温 度
Temperature |
45±3℃ |
时 间
Time |
1-2小时(视沉淀物多寡、槽子脏净程序而定)
1-2 hours (according to amount of deposit and cleaning procedure of bath) |
清槽时机
Time for Changing Bath |
间断作板1-2周若连续作板3-4万(ft2)
Intermittent working for 1-2 circles, and continuous working for 30,000-40,000(ft2) |
五、产品性质
V Product Nature
品名
Product Name |
外观
Appearance |
比重
Specific Gravity |
PH 值
PH Value |
闪火点
Flash Point |
清槽液CL-212
Bath cleaning liquid CL-212 |
无色至淡黄色透明液体
Colorless to light yellow transparent liquid |
1.20-1.40 |
大于12
>12 |
不可燃
Non- combustible |
六、安全防护
VI Safety Protection
清槽剂为腐蚀性物质不可以接触,皮肤衣物不慎碰触,以清水冲洗,眼睛碰触或食入应清水冲洗后立刻送医。
The bath cleaning liquid is corrosive and is not touchable; in case of contact with sin or clothes, flush with clean water, and in case of contact with eyes or inhalation, flush with clean water and then get medical treatment. |
