一、产品简介
I Product Introduction
在高锰酸钾中多层板除胶渣的系统中，作为树脂的膨松剂，用作使孔内在钻孔后的胶渣软化，利于后工序之高锰酸钾把胶渣清除，使孔壁成为亲水性，内不含络合剂，废水处理简单。
In system of removing smear in multi-layer board by potassium permanganate, the sweller can soften the smear in hole after drilling, which is beneficial for later procedure of removing smear by potassium permanganate, so the hole wall will be hydrophilic and has no complexing agent; the treatment of sewage is simple.

二、配槽方法
II Makeup Method

1L槽液 1L solution	主要作用 Main Function	体积（ml） Volume
纯水 Pure water	溶剂 Solvent	700ml
片碱 Sodium hydroxide	提供碱环境 Provide alkaline environment	8g/L
HSD-001	蓬 松 Fluffy	300ml

三、操作条件
III Operating Condition

组份/参数 Component/Parameter	最佳值/工作范围/要求 Optimal value/Work Scope/Requirement
温 度 Temperature	60℃(60-70℃)
时 间 Time	5min(5-10min)
摇 摆 Swing	轻微的机械摆动 Slight mechanical swing
槽体材质 Material of bath	P.P材料 PP material
加热器 Heater	钛、石英或铁弗龙 Titanium, quartz or Teflon
过 滤 Filter	需要 Required

四、添加量
IV Additive Volume
每生产1000ft2补加HSD-001 4L
Supplement HSD-001 4L for producing 1000ft2;
五、控制与维护
V Control and Maintenance
每升工作液处理400-500ft2时换缸
Change bath when each litre of working solution processes 400-500ft2;
六、浓度分析
VI Analysis of Concentration
a) 量取25ml于100ml量筒中；
a) Measure 25ml and place it in a 100ml measuring cylinder;
b) 加水25ml；
b) Add 25ml water;
c) 加入8g NaOH搅拌；
c) Add 8g NaOH and mix;
d) 待静止冷却后读取上层液毫升数；
d) After being still and cooling down, read the ml of upper liquid;
e) 计算：浓度%=ml×9.1
e) Calculation: concentration %=ml×9.1
七、安全防护
VII Safety Protection
使用时请佩戴眼罩、手套及穿安全防护衣。若药液不慎溅及皮肤、眼睛时应用大量清水清洗，严重者应立即就医诊治。
When using it, please wear eyeshade, gloves and protective clothes; in case that solution spatters into eye or on skin, immediately flush with plenty of clean water and get medical treatment if necessary..
