一、产品简介 I Product Introduction 本品是专门针对线路板干菲林工序(D/F)和绿油工序(W/F)以及菲林房生产过程中黑片和黄片的清洁而研制使用本品能有效去菲林使用过程中菲林表面产生的静电、尘埃。对附着于菲林表面的胶渍有很好的溶解能力。直接使用本品清洗菲林的药膜面而不会损伤药膜,经多家线路板生产厂家使用证明,使用本品对减少线路板的开路、短路以及露铜等品质有显着效果。 The product is designed for the cleaning of black and yellow films from the dry film process (D/F) and wet film process (W/F) of board circuit and film room production. The product can effectively remove the static and dust on the surface of film occurred in application process. It can well dissolve the stains attached on surface of film. The product can be used to directly clean the membrane surface of film without damaging it. It has been evidenced by many manufacturer of circuit board that the product has obvious effect on reduction of open-circuit, short-circuit and copper-exposure of circuit board.
二、操作条件 II Operating Conditions 1、主要成分:烃类有机溶剂 1. Main ingredient: hydrocarbons organic solvent 2、外观性质:透明微带异臭液体 2. Nature of Appearance: transparent liquid with smell 3、物理性质: 闪点 -20℃以下 3. Physical property: flash point below -20℃ 燃点 280℃ ignition point 280℃ 4、化学性质: 常温下化学性质稳定,但高温下会发生分解。 4. Chemical property: stable under common temperature, but will decompose at high temperature; 5、清洁能力:对各种胶渍有很强溶解能力,很好的去静电除尘效果,且不会损伤菲林药膜。 5. Cleaning ability: strong dissolving ability for various stains, static and dust without damaging emulsion layer. 6、注意事项:(1)为一级易燃液体,应远离火源,置阴凉处密封储存; 6. Notes: (1) It is class I flammable liquid, so it shall be kept away from fire source and stored in cool and sealed place; (2)属低毒类溶剂,但大量吸入有麻醉性; (2) It is low-noxious solvent, but will induce narcosis due to plenty inhalation; (3)避免溅入眼睛,万一溅入眼睛,立即用大量清水冲洗,并尽快就医; (3) Avoid spattering in eye, in case of any spattering in eye, immediately flush with plenty clean water and get medical treatment; (4)万一发生火灾,可用二氧化碳、泡沫或则干粉灭火器灭火。 (4) In case of fire, use carbon dioxide, foam or dry powder fire extinguisher to extinguishing fire.
三、安全防护 III Safety Protection 本产品须储存于干燥及阴凉(摄氏温度5-30℃)的地方,避免被阳光直射及远离火种,必须与氧化剂分开储存。在存放时,桶盖须朝天,且叠起最高不可超过两层。本药液存储期为一年,非使用时不可打开桶盖。 The product shall be stored in a dry and cool (5-30℃) place, and shall be kept away from direct sunshine and fire as well as oxidizer. For storage, the cylinder shall be with its cover upward, and piled not over two layers. The store period of the product is one year and the cover can only be opened upon using. |
